Scott Scale Gravel 20
Couldn't load pickup availability
Scott Scale Gravel 20
Please contact store for availability or to PRE-ORDER on 04 589 2822 or support@cyclescience.co.nz
The Scale Gravel was put on this planet for going on adventures with attitude. Designed to go the distance over any and all types of terrain, the Scale Gravel is lightweight with agile handling and features multiple mounting options.
Specifications
Scott Scale Gravel 20
Frame
Size: S, M, L and XL
Colour: Ash Green
Frame: Scale HMF Carbon, adjustable head angle, Syncros Cable Integration System, advanced shock & standing damping system, BB92, UDH interface, 12x148mm with 55mm chainline
Fork: Scale Rigid HMF, postmount disc standard, tapered carbon steerer
Shock:
Drivetrain
Crankset: SRAM Eagle 70 Transmission, DUB, 55mm CL, 34T
Pedals:
Chain: SRAM Eagle 70 Transmission
Bottom Bracket: SRAM DUB PF 92 MTB Wide, shell 41x92mm
Rear Derailleur: SRAM S1000 Eagle AXS Transmission 12 Speed, Wireless Electronic Shift System
Front Derailleur:
Derailleur Shifter: SRAM AXS Rocker Pod Controller
Freewheel/Cassette: SRAM Eagle XS-1270 Transmission, 10-52T
Braking System
Brakes: SRAM DB6 4-Piston
Brake Levers:
Wheels
Tyres: Maxxis Aspen 29x2.4", 120TPI Foldable Bead, Tubeless Ready, EXO
Wheels/Rims: Alex Rims X-30S 32H, Sleeve Joint, Tubeless ready
Hubs: [F] Formula CL-811, 15x110mm [R] Formula CL-3248, 12x148mm
Other
Handlebar: Syncros Alloy 6061, T shape Flat, 9°, 740mm
Stem: Syncros Alloy 6061, oversized 31.8mm, 1 1/8", 6° angle
Seat Post: Syncros alloy, 10mm offset, 31.6x400mm
Saddle: Syncros Celista Cut Out
Geometry
Scott Scale Gravel 20
|
S
|
M
|
L
|
XL
|
|
|---|---|---|---|---|
|
A |
||||
|
B |
||||
|
C |
||||
|
D |
||||
|
E |
||||
|
F |
||||
|
G |
||||
|
H |
||||
|
I |
||||
|
J |
||||
|
K |
||||
|
L |
||||
|
M |
||||
|
N |
||||
|
P |
||||
|
Q |
||||
|
R |
