Scott Genius ST 910 TR

Scott Genius ST 910 TR

Made to go up the mountain in a hurry, and down the mountain even faster. The all new Genius ST features a custom Float X Nude shock from FOX and is the perfect bike for those who have an insatiable hunger for rippin' trail.

Specifications

Scott Genius ST 910 TR

Frame

Size: S, M, L and XL
Colour: Green/Black
Frame: Genius Carbon HMF Mainframe with Alloy 6061 Swingarm
Fork: Ohlins RXF36 m.2 Air
Shock: FOX FLOAT X NUDE PE EVOL Piggy Back Trunnion

Drivetrain

Crankset: SRAM GX Eagle Transmission
Pedals:
Chain: SRAM CN GX Eagle Transmission
Bottom Bracket: SRAM DUB PF 92 MTB Wide / shell 41x92mm
Rear Derailleur: SRAM GX Eagle AXS Transmission 12 Speed
Front Derailleur:
Derailleur Shifter: SRAM GX Eagle AXS Rocker Controller
Freewheel/Cassette: SRAM GX Eagle XS 1275 Transmission 10-52

Braking System

Brakes: Shimano XT M8120 4 Piston Disc
Brake Levers:

Wheels

Tyres: [F] Maxxis Minion DHF / 2.6" / 120TPI Foldable, Tubeless Ready / EXO 3C maxxTerra [R] Maxxis Dissector / 2.6" / 60TPI Foldable Tubeless Ready / EXO 3C maxxTerra
Wheels/Rims: Syncros Revelstoke 2.0 6 Bolt, F: 15x110mm, R: 12x148mm, 30mm Tubeless ready rim 28H / XD Driver, Syncros Axle w/Removable Lever, with 6mm Allen, T30 and T25 Tools
Hubs: [F] [R]

Other

Handlebar: Syncros Hixon iC Carbon
Stem:
Seat Post: Syncros Duncan Dropper Post 1.5S / Travel Adjust / 31.6mm
Saddle: Syncros Tofino 2.0 Regular

Geometry

Scott Genuis ST 910 TR

	S	M	L	XL
A head tube angle (+0.6° Headset Setting)	63.9 mm	63.9 mm	63.9 mm	63.9 mm
B head tube length	90.0 mm	100.0 mm	120.0 mm	135.0 mm
C top tube horizontal	570.1 mm	602.2 mm	631.3 mm	659.3 mm
D standover height	728.5 mm	738.5 mm	753.5 mm	768.5 mm
E BB offset	-33.0 mm	-33.0 mm	-33.0 mm	-33.0 mm
F BB height	342.5 mm	342.5 mm	342.5 mm	342.5 mm
G wheel base	1195.0 mm	1229.0 mm	1263.0 mm	1294.0 mm
H BB center to toptube center	-	-	-	-
I BB center to top of seattube	380.0 mm	410.0 mm	440.0 mm	470.0 mm
J seat angle	76.8 mm	77.1 mm	77.2 mm	77.4 mm
K chainstay	440.0 mm	440.0 mm	440.0 mm	440.0 mm
L reach	430.0 mm	460.0 mm	485.0 mm	510.0 mm
M stack	617.0 mm	626.1 mm	644.2 mm	657.8 mm
N stem length	40.0 mm	40.0 mm	40.0 mm	40.0 mm
P fork length	571.0 mm	571.0 mm	571.0 mm	571.0 mm
Q Maximum Seatpost Insertion	173.0 mm	204.0 mm	234.0 mm	265.0 mm
R Crank Length	170.0 mm	170.0 mm	170.0 mm	170.0 mm
