Home » Norco 2026 Range VLT CX C2

Norco 2026 Range VLT CX C2

(0)
$11,999.00
Only 1 left
Low inventory - Hurry up!
Size
Fully assembled delivery

Your bike will arrive fully assembled and ready to ride. No tools or extra setup required!

Norco 2026 Range VLT CX C2

A low-weight, full-power VLT with the newest Bosch technology, made to charge the steeps all day.

The new Bosch Performance Line CX drive unit is lighter and quieter than previous models, without losing the exceptional torque and power the CX system is known for.

The VPSHP (Virtual Pivot Suspension | High Pivot) layout has a rearward axle path that moves out of the way of square-edged hits, maintaining momentum and smooth handling through the rough.

  • A more powerful drive system that's lighter, quieter, and more natural feeling than ever before
  • Balanced geometry for maximum control and handling
  • VPSHP suspension platform - High pivot flow to eat up rough terrain with confidence
  • Bombproof components – spec'd for the toughest trails
  • Ride Aligned™ - Perfect fit, dialed handling and personalized setup in minutes
  • No Other Way Limited Lifetime Warranty
Specifications

Norco 2026 Range VLT CX C2

Frame

Size: S2, S3, S4 and S5
Colour: Sage Slate/Raw Black
Frame: Carbon Frame, 160mm Travel, UDH, Eagle Transmission Compatible, Ride Aligned™
Fork: Rockshox Zeb Base, 170mm travel, 44mm offset, Fender Included
Shock: Rockshox Vivid Air Base, 205x65mm TR

Drivetrain

Crankset: Praxis HD Aluminum Bosch Cranks, 34T, 165mm
Pedals:
Chain: Shimano Deore XT CN-M8100, 12sp
Bottom Bracket: Bosch BDU38
Rear Derailleur: Shimano Deore RD-M6100, 12spd
Front Derailleur:
Derailleur Shifter: Shimano Deore SL-M6100-R, 12spd
Freewheel/Cassette: Shimano Deore CS-M6100-12, 10-51T, 12spd

Braking System

Brakes: TRP Slate EVO, Resin Pads
Brake Levers: TRP Slate EVO

Wheels

Tyres: 14 x 2.125" Wanda P-1135
Wheels/Rims: WTB ST i30,30 mm, 32H, 29"-27.5" F/R
Hubs: [F] Bear Pawls BMB-003,15x110mm Boost, 32H, 6 Bolt [R] Bear Pawls BMB-007, 12x148 Boost, HG, 32H, 6 Bolt

Other

Handlebar: Norco 6061 DB Alloy, 800mm, 25mm Rise
Stem: 6061 Alloy, 40mm Length, 35mm Clamp
Seat Post: TranzX YSP23KL, 31.6mm, 150mm (S2) -170mm (S3) -200mm (S4, S5)
Saddle: Fizik Terra Aidon X5

E-Bike

Drive Unit: Bosch Performance Line CX, 100 Nm
Battery: Bosh Power Tube 800 Wh
Controller:
Display:
Charger:

Geometry

Norco 2026 VLT CX C2

Range VLT CX
2 3 4 5
Wheel Size 29"/27.5" 29"/27.5" 29"/27.5" 29"/27.5"
Travel (mm front/mm rear)
170/160
Reach 441 466 491 516
Stack 631 640 650 659
HTA Head Tube Angle
63.5
OS Fork Offset
44
ST Seat Tube Length 395 415 445 475
STA Effective Seat Tube Angle 76.5 77 77.25 77.5
RC Rear Centre Length 432 436 440 444
RC Rear Centre Length at Sag 442 446 450 454
BBDF/R Bottom Bracket Drop (Front/Rear)
20.5/0
BBH Bottom Bracket Height
353
HTT Horizontal Top Tube 589 613 637 661
WB Wheelbase 1228 1261 1295 1328
SOH Standover 705 711 718 733
HT Head Tube Length 115 125 135 145
Trail
138
Recommended Seatpost Drop 150 170
200
Maximum Post Insertion 250 270 300 330
Stem Length
40
Crank Length
165
Tire Size
2.35" - 2.6"
Water Bottle Compatible 1 x 620 mL
1 x 750 mL
