Merida 2026 eONE SIXTY 675

Merida 2026 eONE SIXTY 675

Maximise your riding range while minimising your spend. Our hard-hitting aluminium frame gets our award-winning suspension and sizing, paired with a 750 Wh removable battery and optional range extender. Add in Marzocchi suspension and a tough Shimano drivetrain, and you're set.

Say hello to a huge range and ride fun without saying goodbye to your budget. The eONE-SIXTY 675 gets a durable aluminium frame and user-removable 750 Wh battery with an optional 360 Wh range extender, but we combine our award-winning handling and suspension with wallet-friendly kit to give you maximum bang for your buck. A stout Marzocchi Z1 170 mm fork and Bomber Air shock keep trail chaos under control, while the Shimano Deore Linkglide drivetrain is tough enough for e-bike use, day in, day out.

With the latest eONE-SIXTY, the next descent is always about to start. With an all-aluminium frame, it offers maximum value and maximum battery range, thanks to a powerful drive unit paired with a removable 750 Wh battery and optional 360 Wh range extender. The only reason to stop will be because you have to. With our incredibly capable geometry derived from the award-winning ONE-SIXTY enduro range, we've got handling that'll help you conquer the toughest climbs as well as the most grin-inducing descents, while our proven FAST kinematic suspension will take care of anything the trail throws at it. This low-maintenance flexstay design offers 174 mm of rear wheel travel to go with 170 mm at the front, with size-tuned progression to maximise performance for all sizes of riders. You can run it with the latest coil shocks without any worries too. With mixed size 29" front and 27.5" rear wheels as standard for playful handling, you can switch to a focused full 29er setup without messing up the geometry, thanks to our flip chip design. With low standover heights across all sizes, you can choose between a longer frame for more stable handling or a shorter one for an agile feel, while some models feature our ground-breaking 30-230 mm travel-adjustable dropper post. *except eONE-SIXTY 400

• Fourth generation LITE aluminium frame with 174 mm rear wheel travel
• Marzocchi Z1 fork with 170 mm travel and Bomber Air rear shock
• Highly durable Shimano Deore Linkglide drivetrain and MERIDA tubeless-ready wheelset
• User-removable 750 Wh battery with optional 360 Wh range extender, powerful Shimano EP801 drive unit
• Mixed wheel size as standard with option to full 29"
• Reach-based AGILOMETER sizing system with long-travel dropper posts on all sizes

Specifications

Merida 2026 eONE SIXTY 675

Frame

Size: Short, Mid, Long, X-Long
Colour: Gunmetal Grey(BLack)
Frame: eONE-SIXTY LITE IV, MAT aluminium, 160 STR, 29x2.6" max. WHS, 148x12 AST
Fork: Marzocchi Z1 eMTB, Air, 170 STR, Tapered, 44mm fork offset, 29x2.6" max WHS,
Shock: Marzocchi Bomber Air, platform

Drivetrain

Crankset: FSA 1x Steel Chainring, 36t
Pedals:
Chain: Sram Eagle 70 Flattop Chain,
Bottom Bracket:
Rear Derailleur: Sram Eagle 70 Transmission,
Front Derailleur:
Shifter: [F] Sram Dropper Lever MMX [R] Sram Eagle 70 Transmission Shifter
Freewheel/Cassette: Sram CS XS 1270 T-TYPE 10-52,12

Braking System

Brakes: Sram DB6 stealth, 4 piston
Brake Levers:

Wheels

Tyres: [F] Maxxis Assegai, 29x2.5 ", fold, TR EXO+ 3C MaxxGrip [R] Maxxis Minion DHR II, 27.5x2.4 ", fold, 3C DD TR MaxxTerra
Wheels/Rims: Reynolds 309 Enduro Comp, 30 IWR, MAT aluminium, Tubeless ready (tubeless tape installed), front 29", rear 27.5"
Hubs: [F] Novatec SL-ELITE D041SB-B15, 110x15 WHF, 32 SPH, 6 bolt [R] Novatec SL-TEAM D462SB-S3S-B12-11S, 148x12 WHR, 32 SPH, 6 bolt

Other

Handlebar: MERIDA EXPERT eTR, 780 WHB
Stem: MERIDA EXPERT eTR II, MAT aluminium, 35 DSH, 0 ASD, Supernova mount,
Seat Post: MERIDA EXPERT TR II, 34.9 DSP, 0 SSB, XS: 125mm travel - S: 150mm travel - M: 170SPT - L: 200mm travel - XL: 230mm travel
Saddle: MERIDA COMP SL, V-mount, incl. MERIDA minitool

E-Bike

Drive Unit: Shimano EP801, 85Nm
Battery: Shimano BT-EN817, 712Wh
Controller:
Display: Shimano SC-EM800,
Charger:

Extras

Fenders:
Kickstand:
Lights: [F] Lezyne Hekto StVZO E350+ Reverse, reverse MERIDA Custom Mount [R] LEZYNE LED FEMTO USB REAR STVZO,
Carrier:

Geometry

Merida 2026 eONE SIXTY 675
