Marin 2025 DSX 1
Couldn't load pickup availability
Your bike will arrive fully assembled and ready to ride. No tools or extra setup required!
Marin 2025 DSX 1
LONG DISTANCE MIXED SURFACE COMMUTING
GRAVEL RIDING
ADVENTURE ON AND OFF-ROAD RIDING
Hopping up to a higher-spec Series 3 aluminum frame, the Marin DSX 1 has a whole heap of upgrades over the base spec version. Bolt-thru axles add stiffness and a carbon fork drops the weight and adds even more mounting points for bikepacking bags. There’s also an 11-speed 1X Shimano Deore drivetrain, WTB Riddler tires, Tektro hydraulic brakes and plenty of reliable Marin components.
Specifications
Marin 2025 DSX 1
Frame
Colour: Grey
Frame: Series 3 DSX, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Mudguard and Rack Mounts, Flat Mount Disc, 142x12mm Thru-Axle
Fork: Marin Full Carbon w/ Tapered Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Shock:
Drivetrain
Crankset: Forged Aluminum, 42T Steel Narrow Wide Chainring
Chain: KMC X11
Bottom Bracket: Sealed Cartridge
Rear Derailleur: Shimano Deore, RDM5100, 11-Speed
Front Derailleur:
Derailleur Shifter: Shimano Deore, SLM5100, 11-Speed
Freewheel/Cassette: Shimano, CSM5100, 11-Speed, 11-51T
Braking System
Brakes: [F] and [R] Tektro HD-R280 Flat Mount Hydraulic Disc, 160mm Rotor
Brake Levers: Tektro Hydraulic
Wheels
Tyres: [F] and [R] WTB Riddler, 700Cx45mm
Wheels/Rims: [F] and [R] Marin Aluminum Double Wall, 21mm Inner, Disc Specific
Hubs: [F] Forged Aluminum, 100x12mm, Disc, 32H [R] Forged Aluminum Alloy, 142x12mm, Disc, 32H
Other
Handlebar: Marin Mini-Riser
Stem: Marin 3D Forged Alloy
Saddle: Marin DSX
Seat Post: Marin Alloy
Geomerty
Marin 2025 DSX 1
| S | M | L | XL | |
| STACK | 583.2 | 601.8 | 629.7 | 657.6 |
| REACH | 400 | 425 | 440 | 455 |
| HEADTUBE ANGLE | 68.5° | 68.5° | 68.5° | 68.5° |
| HEADTUBE LENGTH | 100 | 120 | 150 | 180 |
| SEATTUBE ANGLE | 74° | 74° | 74° | 74° |
| SEATTUBE LENGTH | 430 | 480 | 520 | 558 |
| TOPTUBE EFFECTIVE | 567.23 | 597.6 | 620.6 | 643.6 |
| BB HEIGHT | 277.5 | 277.5 | 277.5 | 277.5 |
| BB DROP | 82 | 82 | 82 | 82 |
| CHAINSTAY | 425 | 425 | 425 | 425 |
| WHEELBASE | 1065 | 1097.3 | 1123.3 | 1149.3 |
| STANDOVER HEIGHT | 667 | 708 | 738 | 761 |
| FORK OFFSET | 47 | 47 | 47 | 47 |
