Giant 2025 Talon 29 4
Couldn't load pickup availability
Your bike will arrive fully assembled and ready to ride. No tools or extra setup required!
Giant 2025 Talon 29 4
The mountain bike experience starts here. With a redesigned frame that’s now lighter and more durable, along with a smooth-riding suspension fork, thru-axle hubs*, and a 1x drivetrain*, this aluminum hardtail is everything an aspiring MTB rider needs to evolve and advance. *on select models
Modern MTB Design
Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models
Off-Road Control
New geometry is optimized for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size. All models have clearance for high-volume tires (up to 2.4-inch) for traction and grip on technical terrain.
Light and Durable
All-new ALUXX aluminum frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.
Specifications
Giant 2025 Talon 29 4
Frame
Colour: Black and Radiant Orange
Frame: ALUXX-Grade aluminium, disc
Fork: SR Suntour XCE (TBC)
Shock: NA
Drivetrain
Crankset: Prowheel Forged (TBC)
Pedals:
Chain: KMC 8.3
Bottom Bracket: Cartridge
Rear Derailleur: MicroShift Acolyte, M5185M w/clutch
Front Derailleur: NA
Derailleur Shifter: MicroShift Acolyte, 1x8
Freewheel/Cassette: MicroShift H083, 11x46
Braking System
Brakes: [F] and [R] TKB-172, mechanical [F]160mm, [R]160mm rotors
Brake Levers: Alloy
Wheels
Tyres: [F] and [R] Maxxis Ikon 27.5" or 29x2.2", wire bead
Wheels/Rims: [F] and [R] Giant GX03V 29 or 27.5, alloy, double wall
Hubs: [F] and [R] Alloy, sealed
Other
Handlebar: Giant Connect Trail, 31.8mm
Stem: Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (29)
Saddle: Giant ErgoContact Trail
Seat Post: Giant Sport, 30.9mm
Geometry
Giant 2025 Talon 29 4
| S (29") | M (29") | L (29") | XL (29") | XXL (29") | XS (27.5") | S (27.5") | ||
| A | Seat Tube Length (MM) | 380 | 420 | 450 | 480 | 500 | 345 | 375 |
| B | Seat Tube Angle | 74.5° | 74.5° | 74.5° | 74.5° | 74.5° | 74.0° | 74.0° |
| C | Top Tube Length (MM) | 581 | 604 | 629 | 653 | 676 | 542 | 562 |
| D | Head Tube Length (MM) | 95 | 105 | 125 | 140 | 155 | 90 | 90 |
| E | Head Tube Angle | 67.5° | 67.5° | 67.5° | 67.5° | 67.5° | 67.0° | 67.0° |
| F | Fork Rake (MM) | 44 | 44 | 44 | 44 | 44 | 44 | 44 |
| G | Trail (MM) | 108.9 | 108.9 | 108.9 | 108.9 | 108.9 | 105.2 | 105.2 |
| H | Wheelbase (MM) | 1139 | 1164 | 1191 | 1217 | 1242 | 1084 | 1104 |
| I | Chain Stay Length (MM) | 455 | 455 | 455 | 455 | 455 | 440 | 440 |
| J | Bottom Bracket Drop (MM) | 55 | 55 | 55 | 55 | 55 | 45 | 45 |
| K | Stack (MM) | 597 | 606 | 625 | 639 | 653 | 548 | 548 |
| L | Reach (MM) | 415 | 436 | 456 | 476 | 495 | 385 | 405 |
| M | Stand Over Height (MM) | 715 | 709 | 709 | 710 | 707 | 684 | 684 |
| O | Stem Length (MM) | 50 | 60 | 70 | 80 | 90 | 40 | 50 |
| P | Crank Length (MM) | 170 | 170 | 170 | 175 | 175 | 165 | 165 |
| Q | Wheel Size | 29 | 29 | 29 | 29 | 29 | 27 | 27 |
| Q | Wheel Size | 29 | 29 | 29 | 29 | 29 | 27 | 27 |
